SuperChassis LA15TQC-R860AWSuperChassis LA15TQC-R860AW

Key Features


  1. 1U Optimized for CloudDC motherboard with S-AIOM support, support MB size up to 12.3" x 13.4"
  2. 4 x 3.5"(tool-less) or 2.5"(screw) hot-swap SAS3/SATA drive bay
  3. SAS or enterprise SATA HDD only recommended
  4. 1U SAS/SATA Backplane with SES2 support
  5. 1U 860W Redundant power supply Platinum level, 24Pin output
  6. 2x full-height & full-length expansion slot(s) 2x S-AIOM expansion slot(s)
  7. 4 x 40x56mm counter-rotation PWM fan(s) by default, 2x as optional
  8. Support Service Tag for system information
Specifications Resources Parts List
Specifications
Product SKUs
CSE-LA15TQC-R860AW
Form Factor
  • 1U Optimized for CloudDC motherboard with S-AIOM support, support MB size up to 12.3" x 13.4"
Processor Support
  • Dual and Single Intel® and AMD processors
Dimensions
Height
  • 1.7" (43 mm)
Width
  • 17.2" (437 mm)
Depth
  • 25.6" (650 mm)
Gross Weight
  • 28 lbs (12.7 kg)
Packaging (W x H x L)
  • 23.7" (602 mm) x 7.7" (196 mm) x 34.1" (866 mm)
Available Color
  • Black
Expansion Slots
  • 2x Full-height expansion slot(s)
  • 2x S-AIOM expansion slot(s)
Drive Bay
